คุณสมบัติ | รายละเอียด |
---|---|
Thread Size | M8 |
Sensor Technology | Inductive |
Body Style | Barrel |
Detection Range | 6 mm |
Output Function | NO |
Digital Switching Output Type | PNP |
Connection Type | M8 |
Supply Voltage | 6 → 36 V dc |
IP Rating | IP67 |
Length | 46mm |
Mounting Type | Non-Flush |
Housing Material | Stainless Steel |
Width | 8mm |
Maximum DC Voltage | 36V |
Minimum Operating Temperature | -25°C |
Standards Met | CE, cULus Listed, EAC |
Maximum Switching Frequency | 400Hz |
Switching Frequency | 400 Hz |
Shielding | Unshielded |
Reverse Polarity Protection | Yes |
Short Circuit Overload Protection | Yes |
Maximum Operating Temperature | +75°C |
Switching Current | 100 mA |
