คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 110V ac |
| Contact Configuration | DPDT |
| Mounting Type | DIN Rail |
| Number of Poles | 2 |
| Load Current Rating | 8A |
| Maximum Input Voltage | 250V ac |
| Switching Voltage | 110 V ac → 250V ac |
| Terminal Type | Screw |
| Depth | 15.8mm |
| Height | 52mm |
| Length | 75mm |
| Series | 2RM |
| Contact Material | Silver Alloy |
| Input Current | 8A |
| Operating Temperature Range | -40 → +85°C |
| Special Features | Change Over Contacts, Supplied Complete, Relay, LED, Socket, Ejector Clip and Identification Label, 1Part Number for Simple Ordering AC & DC Coils, Supply Status LED as Standard 35mm Din Rail Mounting, 2 Socket Types For Ease of Installation, 12A and 16A Versions |
| Standards Met | CE, cURus |
| Relay Switching Classification | Interface Relay Module |
| Minimum Operating Temperature | -40°C |
| Turn Off Time | 8ms |
| Turn On Time | 15ms |
| Maximum Operating Temperature | +85°C |
| Control Resistance | 100mΩ |
| Life | 100000 (AC, Mechanical), 100000 (DC, Electrical), 10000000 (DC, Mechanical), 50000 (AC, Electrical) |
| Dimensions | 75 x 15.8 x 52mm |
