คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 5V dc |
| Contact Configuration | DPDT |
| Mounting Type | PCB Mount |
| Maximum Switching Current AC | 2 A |
| Maximum Switching Current DC | 3 A |
| Maximum Switching Voltage AC | 250V |
| Maximum Switching Voltage DC | 220V |
| Maximum Switching Power DC | 90 W |
| Series | HFD2 |
| Latching | No |
| Length | 20.2mm |
| Depth | 10.1mm |
| Height | 10.6mm |
| Dimensions | 20.2 x 10.2 x 10.6mm |
| Terminal Type | PCB Pin |
| Number of Poles | 2 |
| Switching Current | 3A |
| Contact Material | Gold Plated |
| Features | Bifurcated Contacts, High Sensitive, High Switching Capacity |
| Operating Temperature Range | -40 - +85°C |
| Coil Resistance | 167Ω |
| Maximum Switching Power AC | 125VA |
| Life | 1 x 10^8 cycles |
| Maximum Operating Temperature | +85°C |
| Coil Power | 150mW |
| Minimum Operating Temperature | -40°C |
| Relay Switching Classification | Subminiature DIP Relay |
