คุณสมบัติ | รายละเอียด |
|---|---|
| Series | ÖLFLEX CLASSIC 100 |
| Number of Cores | 4 |
| Cross Sectional Area | 1.5 mm² |
| Screened/Unscreened | Unscreened |
| Length | 50m |
| Control Cable Type | YY |
| Sheath Colour | Grey |
| American Wire Gauge | 16 AWG |
| CPR Certification | Eca |
| Outer Diameter | 7.2mm |
| Sheath Material | PVC |
| Standards Met | EAC |
| Fire Behaviour | Flame Retardant |
| Current Rating | 18 A |
| Insulation Material | PVC |
| Oil Resistant | Yes |
| Filler Material | Non-Wicking Filler |
| Minimum Operating Temperature | -40°C |
| Earth Cable | Yes |
| Maximum Operating Temperature | +70°C |
| Voltage Rating | 300/500 V |
| Conductor Resistance | 13.5 Ω/km |
| Minimum Bend Radius | Fixed - 4 x D Occasional flexing - 15 x D |
| Core Strands | 30/0.25 mm |
| Conductor Material | Copper |
