คุณสมบัติ | รายละเอียด |
|---|---|
| Series | RST |
| Number of Cores | 3 |
| Cross Sectional Area | 0.34 mm² |
| Sheath Material | PUR |
| Sheath Colour | Black |
| Length | 5m |
| Connector 1 Gender | Male |
| Connector 1 Orientation | Straight |
| Connector 1 Number of Contacts | 3 |
| Connector 1 | M12 |
| Connector 2 | M8 |
| Connector 2 Gender | Female |
| Connector 2 Orientation | Right Angle |
| Connector 2 Number of Contacts | 3 |
| Coding | A |
| Shielding | Unshielded |
| Shielded/Unshielded | Unshielded |
| Voltage Rating | 30 V |
| Current Rating | 4 A |
| IP Rating | IP65, IP67, IP69K |
| Cable Shape | Round |
| American Wire Gauge | 22 AWG |
| Insulation Material | PP |
| Fire Behaviour | Flame Retardant |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +90°C |
| Operating Temperature Range | -40 → +90 °C |
| Outer Diameter | 4.30mm |
| Oil Resistant | Yes |
| Minimum Bend Radius | 5 x cable diameter |
| Conductor Material | Copper |
11348 RKT 4-07/2 M
BCC M313-0000-10-001-PX0334-050
NEBB-M8G3-P-5-LE3
ASB 2-VAD 2B-1-3-226/1MP7
T4161220005-005
