คุณสมบัติ | รายละเอียด |
|---|---|
| Stroke | 500mm |
| Bore | 100mm |
| Action | Double |
| Manufacturer Series | PRA |
| Length | 230mm |
| Pneumatic Connection | G 1/2 |
| Piston Rod Thread Gender | Male |
| Cushioning Type | Air |
| Dimensions | 230 x 113 x 113mm |
| Width | 113mm |
| Maximum Operating Pressure | 12 bar |
| Height | 113mm |
| VDMA Standard | 24562 |
| Test Weight | 3.66 kg @ 0 mm |
| Diameter | 100mm |
| Minimum Operating Temperature | -20°C |
| ISO Standard | 15552 |
| Maximum Operating Temperature | +80°C |
| Stroke Interval Weight | 0.23 kg @ 25 mm |
