คุณสมบัติ | รายละเอียด |
---|---|
Thread Size | M12 |
Sensor Technology | Inductive |
Detection Range | 4 mm |
Body Style | Barrel |
Digital Switching Output Type | NPN |
Output Function | NO |
Connection Type | M12 |
Supply Voltage | 10 → 30 V dc |
Length | 47.1mm |
IP Rating | IP67, IP67G, IP69K |
Mounting Type | Flush |
Width | 12mm |
Housing Material | Brass |
Maximum DC Voltage | 30V |
Minimum Operating Temperature | -25°C |
Switching Current | 16 mA |
Communication Protocol | IO-LINK |
Maximum Switching Frequency | 1kHz |
Shielding | Shielded |
Depth | 17mm |
Short Circuit Overload Protection | Yes |
Series | E2E-NEXT |
Switching Frequency | 1 kHz |
Maximum Operating Temperature | +70°C |
Reverse Polarity Protection | Yes |
