คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 12V dc |
| Contact Configuration | SPDT |
| Mounting Type | DIN Rail |
| Number of Poles | 1 |
| Load Current Rating | 50mA |
| Load Voltage Rating | 30V |
| Minimum Input Voltage | 10.8V |
| Maximum Input Voltage | 13.2V |
| Terminal Type | Push In |
| Switching Voltage | 440V ac |
| Depth | 6.2mm |
| Height | 90mm |
| Length | 88mm |
| Series | G2RV-ST |
| Contact Material | Ag Alloy |
| Input Current | 27.9mA |
| Relay Type | Electro Mechanical |
| Control Resistance | 100MΩ |
| For Use With | Industrial Control Equipment |
| Accessory Type | Relay Module |
| Special Features | LED, Mechanical Indicator, Transparent Case |
| Turn Off Time | 20 (For DC)/40(For AC)ms |
| Life | 5000000 cycles |
| Operating Temperature Range | -40 → 55°C |
| Turn On Time | 20ms |
| Standards Met | CE, CULus |
| Relay Switching Classification | Electromechanical Relay |
| Input Voltage Range | 10.8-13.2V |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +55°C |
| Dimensions | 88 x 90 x 6.2mm |
| Input Resistance | 0.4kΩ |
