คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 230V ac |
| Contact Configuration | SPDT |
| Mounting Type | DIN Rail |
| Number of Poles | 1 |
| Load Current Rating | 6A |
| Maximum Input Voltage | 253V |
| Minimum Input Voltage | 184V |
| Load Voltage Rating | 250V ac |
| Terminal Type | Push In |
| Switching Voltage | 440V ac |
| Depth | 6.2mm |
| Height | 90mm |
| Length | 88mm |
| Series | G2RV-ST |
| Contact Material | Ag Alloy |
| Input Current | 6.8mA |
| Control Resistance | 100MΩ |
| Life | 70000 cycles |
| Turn On Time | 20ms |
| Input Resistance | 34kΩ |
| Input Voltage Range | 184-253V |
| Dimensions | 88 x 90 x 6.2mm |
| Turn Off Time | 20 (For DC)/40(For AC)ms |
| Accessory Type | Relay Module |
| Special Features | LED, Mechanical Indicator, Transparent Case |
| Standards Met | CE, CULus |
| Relay Switching Classification | Electromechanical Relay |
| Relay Type | Electro Mechanical |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +55°C |
| Operating Temperature Range | -40 → 55°C |
| For Use With | Industrial Control Equipment |
