คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 5V dc |
| Contact Configuration | DPDT |
| Mounting Type | Surface Mount |
| Maximum Switching Current DC | 1 A |
| Maximum Switching Voltage AC | 125V ac |
| Maximum Switching Voltage DC | 60V dc |
| Series | HFD2 |
| Maximum Switching Power DC | 90 W |
| Latching | No |
| Length | 10mm |
| Depth | 6.5mm |
| Height | 5.2mm |
| Dimensions | 10 x 6.5 x 5.2mm |
| Terminal Type | Surface Mount |
| Switching Current | 1A |
| Number of Poles | 2 |
| Isolation Coil To Contact | 750V |
| Electrical Life | 100000 Operations |
| Maximum Operating Temperature | +70°C |
| Operating Temperature Range | -40 - +70°C |
| Features | Low Dimension And Weight Combines To Improve Mounting Efficiency, RoHS Complaint |
| Coil Power | 100mW |
| Contact Material | Silver |
| Minimum Operating Temperature | -40°C |
| Coil Resistance | 237Ω |
| Maximum Switching Power AC | 125VA |
V23079A1006B301 2-1393788-0
V23101D 107A201
