คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 24V dc |
| Contact Configuration | DPST |
| Mounting Type | Plug In |
| Switching Current | 25A |
| Number of Poles | 2 |
| Latching | No |
| Terminal Type | Plug In |
| Maximum Switching Voltage AC | 277V |
| Maximum Switching Voltage DC | 30V dc |
| Length | 50mm |
| Coil Resistance | 300Ω |
| Coil Power | 1.92W |
| Life | 200000 Operations |
| Depth | 33mm |
| Minimum Operating Temperature | -50°C |
| Height | 35mm |
| Maximum Operating Temperature | +55°C |
| Isolation Coil To Contact | 5kVrms |
| Contact Material | Silver Alloy |
| Maximum Switching Power AC | 6.925 kVA |
| Application | Domestic Appliances |
