คุณสมบัติ | รายละเอียด |
---|---|
Thread Size | M12 |
Sensor Technology | Inductive |
Detection Range | 50 mm |
Body Style | Block |
Digital Switching Output Type | PNP |
Output Function | NO |
Connection Type | M12 |
Supply Voltage | 10 → 60 V dc |
IP Rating | IP68 |
Length | 65mm |
Mounting Type | Flush |
Width | 84mm |
Housing Material | PBT |
Maximum DC Voltage | 60V |
Minimum Operating Temperature | -25°C |
Shielding | Unshielded |
Short Circuit Overload Protection | Yes |
Depth | 40mm |
Standards Met | CCC Certified, cCSAus Listed, CE Certified, cULus Listed, EAC Certified, EN 60947-5-2, IEC 60947-5-2 |
Maximum Switching Frequency | 80Hz |
Switching Frequency | 80 Hz |
Switching Current | 200 mA |
Maximum Operating Temperature | +70°C |
Reverse Polarity Protection | Yes |
