คุณสมบัติ | รายละเอียด |
|---|---|
| Series | SAC-8P |
| Number of Cores | 8 |
| Cross Sectional Area | 0.25 mm² |
| Sheath Colour | Black/Grey |
| Length | 10m |
| Sheath Material | PUR |
| Connector 1 Orientation | Straight |
| Connector 1 | M12 |
| Connector 1 Gender | Male |
| Connector 1 Number of Contacts | 8 |
| Connector 2 | Unterminated |
| Coding | A |
| Shielding | Unshielded |
| Voltage Rating | 30 V |
| Current Rating | 2 A |
| IP Rating | IP65, IP67, IP68 |
| Conductor Material | Bare Cu litz wires |
| Maximum Operating Temperature | +90°C |
| Minimum Bend Radius | 8 x D (Fixed), 10 x D (Flexible) |
| Insulation Material | PP |
| Operating Temperature Range | -25 → +90 °C |
| Connector 1 Housing Gender | Male |
| Outer Diameter | 5.9mm |
| Fire Behaviour | Flame Retardant |
| Minimum Operating Temperature | -25°C |
| Standards Met | cULus |
| American Wire Gauge | 24 AWG |
| Oil Resistant | Yes |
| Cable Shape | Twisted Pair |
M12A-17BMMM-SL8B01
T4162AB9L25-005
