คุณสมบัติ | รายละเอียด |
|---|---|
| Cross Sectional Area | (Signal Line) 0.34 mm², (Power Line) 0.75 mm² |
| Number of Cores | 12 |
| Sheath Colour | Black |
| Sheath Material | PUR |
| Length | 5m |
| Connector 1 Gender | Female |
| Connector 1 Number of Contacts | 12 |
| Connector 1 Orientation | Right Angle |
| Connector 1 | M23 |
| Connector 2 | Unterminated |
| Voltage Rating | 48 V ac, 60 V dc |
| IP Rating | IP65, IP67 |
| Outer Diameter | 8.5mm |
| Cable Shape | Twisted Pair |
| Minimum Bend Radius | 7.5 x D (Fixed), 10 x D (Flexible) |
| Conductor Material | Bare Cu litz wires |
| Connector 1 Housing Gender | Female |
| Insulation Material | PVC |
| American Wire Gauge | 22, 18 AWG |
| Oil Resistant | Yes |
