คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 24V ac |
| Contact Configuration | SPDT |
| Mounting Type | Plug In |
| Switching Current | 16A |
| Number of Poles | 1 |
| Latching | No |
| Terminal Type | Plug In |
| Maximum Switching Voltage AC | 250V ac |
| Maximum Switching Voltage DC | 30V dc |
| Length | 28mm |
| Coil Power | 480W |
| Depth | 21.5mm |
| Contact Material | Silver Alloy |
| Standards Met | CE, CQC, CULus, RoHS Compliant |
| Height | 36mm |
| Maximum Operating Temperature | +55°C |
| Isolation Coil To Contact | 2kV ac |
| Minimum Operating Temperature | -25°C |
| Life | 100000 (Electrical) cycles, 10000000 (Mechanical) cycles |
| Maximum Switching Power DC | 900mW |
| Maximum Switching Power AC | 1.2VA |
| Application | General Purpose |
G2R-1-SNI DC24(S)
G2R-1-SNDI-AP3 DC24(S)
PT570512 8-1419111-6
V23061B1007A301
