คุณสมบัติ | รายละเอียด |
|---|---|
| Number of Cores | 3 |
| Cross Sectional Area | 0.34 mm² |
| Screened/Unscreened | Unscreened |
| Length | 100m |
| Control Cable Type | LIYY |
| Cable Shape | Multi-Conductor |
| Sheath Colour | Grey |
| CPR Certification | Eca |
| American Wire Gauge | 22 AWG |
| Outer Diameter | 4.1mm |
| Sheath Material | PVC |
| Standards Met | Euroclass Eca |
| Conductor Material | Bare Copper |
| Voltage Rating | 300 V |
| Earth Cable | No |
| Fire Behaviour | Flame Retardant NF C 32-070/C2, IEC 60332-1 |
| Minimum Operating Temperature | -30°C |
| Filler Material | PVC |
| Conductor Resistance | 58.9 Ω/km |
| Screen Type | Unscreened |
| Maximum Operating Temperature | +70°C |
| Oil Resistant | No |
| Minimum Bend Radius | 15 x 4.1 (Moved), 7 x 4.1 (Fixed) |
| Insulation Material | PVC |
| Current Rating | 5A |
