คุณสมบัติ | รายละเอียด |
|---|---|
| Cross Sectional Area | 0.25 mm² |
| Number of Cores | 4 |
| Sheath Material | PVC |
| Length | 2m |
| Sheath Colour | Purple |
| Connector 1 Gender | Female |
| Connector 1 Number of Contacts | 5 |
| Connector 1 Orientation | Straight |
| Connector 1 | M12 |
| Connector 2 | M12 |
| Connector 2 Orientation | Straight |
| Connector 2 Number of Contacts | 5 |
| Connector 2 Housing Gender | Male |
| Connector 2 Gender | Male |
| Shielding | Tinned Copper Braid |
| Shielded/Unshielded | Shielded |
| Current Rating | 4 A |
| Voltage Rating | 60 V |
| IP Rating | IP67 |
| Insulation Material | PVC |
| Outer Diameter | 6.3mm |
| Connector 1 Housing Gender | Female |
| Operating Temperature Range | -25 °C→+75 °C |
| Number of Strands | 7 |
| Maximum Operating Temperature | +75°C |
| Cable Shape | Multicore |
| Minimum Operating Temperature | -25°C |
| Conductor Material | Copper |
| Core Strands | 7/0.2 mm |
