คุณสมบัติ | รายละเอียด |
|---|---|
| Series | YN2D24 |
| Number of Cores | 4 |
| Cross Sectional Area | 0.34 mm² |
| Sheath Material | Polyurethane PUR |
| Sheath Colour | Black |
| Length | 2m |
| Connector 1 Gender | Male |
| Connector 1 Number of Contacts | 4 |
| Connector 1 Orientation | Straight |
| Connector 1 | M12 |
| Connector 2 Orientation | Straight |
| Connector 2 Number of Contacts | 4 |
| Connector 2 Housing Gender | Male |
| Connector 2 | RJ45 |
| Connector 2 Gender | Male |
| Coding | D |
| Shielding | Shielded |
| Shielded/Unshielded | Shielded |
| Voltage Rating | 48/60 V ac/dc |
| Current Rating | 1.5 A |
| IP Rating | IP67 |
| Maximum Operating Temperature | +70°C |
| Standards Met | CE |
| Minimum Bend Radius | 80.4 mm |
| American Wire Gauge | 22 AWG |
| Minimum Operating Temperature | -30°C |
| Outer Diameter | 6.7mm |
| Operating Temperature Range | -30 → 70 °C |
| Connector 1 Housing Gender | Male |
