คุณสมบัติ | รายละเอียด |
|---|---|
| Port Connection | G 1/2 |
| Maximum Operating Pressure | 10 bar |
| Manufacturer Series | AW40 |
| Filtration Size | 5µm |
| Pressure Gauge Port | G 1/8 |
| Pressure Gauge Port Thread Size | 1/8 in |
| Port Connection Thread Size | 1/2 in |
| Maximum Ambient Operating Temperature | +60°C |
| Minimum Process Operating Temperature | -5°C |
| Ambient Operating Temperature Range | -5 - +60°C |
| Bowl Material | Polycarbonate |
| Proof Pressure | 1.5MPa |
| Process Operating Temperature Range | -5 - +60°C |
| Minimum Ambient Operating Temperature | -5°C |
| Maximum Process Operating Temperature | +60°C |
| Pressure Gauge Port Thread Standard | G |
| Port Connection Thread Standard | G |
