คุณสมบัติ | รายละเอียด |
---|---|
Coil Voltage | 48 V ac |
Number of Poles | 3 |
Contact Voltage Rating | 1 kV ac |
Contact Current Rating | 80 A |
Range | TeSys D |
Series | LC1D |
Power Rating | 45 kW |
Normal State Configuration | 3NO |
Auxiliary Contact Configuration | 1NO + 1NC |
Number Of Auxiliary Contacts | 2 |
Terminal Type | Screw |
Length | 127mm |
Width | 85mm |
Depth | 125mm |
Better World Verification | Green Premium |
Better World Product | Yes |
Maximum Operating Temperature | +60°C |
Minimum Operating Temperature | -5°C |
