คุณสมบัติ | รายละเอียด |
|---|---|
| Cross Sectional Area | 0.25 mm² |
| Number of Cores | 4 |
| Sheath Material | Polyvinyl Chloride PVC |
| Length | 5m |
| Sheath Colour | Grey |
| Connector 1 Number of Contacts | 4 |
| Connector 1 | M8 |
| Connector 1 Gender | Female |
| Connector 2 | Unterminated |
| Shielded/Unshielded | Unshielded |
| Current Rating | 4 A |
| Voltage Rating | 30 V |
| IP Rating | IP69K |
| Cable Shape | Multicore |
| Maximum Operating Temperature | +80°C |
| Minimum Operating Temperature | -5°C |
| Insulation Material | PVC |
| Minimum Bend Radius | 48 mm |
| American Wire Gauge | 25 AWG |
| Outer Diameter | 4.8mm |
| Connector 1 Housing Gender | Female |
