คุณสมบัติ | รายละเอียด |
---|---|
Thread Size | M12 |
Sensor Technology | Inductive |
Detection Range | 4 mm |
Body Style | Barrel |
Output Function | NO |
Digital Switching Output Type | NPN |
Connection Type | M12 |
Supply Voltage | 10 → 30 V dc |
Length | 45mm |
IP Rating | IP68, IP69K |
Mounting Type | Flush |
Housing Material | Stainless Steel |
Width | 12mm |
Maximum DC Voltage | 30V |
Minimum Operating Temperature | -40°C |
Maximum Switching Frequency | 2kHz |
Series | IMB |
Switching Current | 200 mA |
Maximum Operating Temperature | +100°C |
Switching Frequency | 2 kHz |
Shielding | Shielded |
Short Circuit Overload Protection | Yes |
Reverse Polarity Protection | Yes |
