คุณสมบัติ | รายละเอียด |
|---|---|
| Thread Size | M18 |
| Sensor Technology | Inductive |
| Body Style | Barrel |
| Detection Range | 8 mm |
| Output Function | NO+NC |
| Digital Switching Output Type | PNP |
| Connection Type | M12 |
| Supply Voltage | 10 → 30 V dc |
| Length | 69mm |
| IP Rating | IP67 |
| Mounting Type | Non-Flush |
| Width | 18mm |
| Housing Material | Metal |
| Maximum DC Voltage | 30V |
| Minimum Operating Temperature | -25°C |
| Reverse Polarity Protection | Yes |
| Maximum Operating Temperature | +75°C |
| Series | IME12 |
| Short Circuit Overload Protection | Yes |
| Shielding | Unshielded |
| Maximum Switching Frequency | 1kHz |
| Switching Frequency | 1 kHz |
| Switching Current | 200 mA |
IME18-05BPSZC0S
BES 516-3007-G-E4-C-S49-00,2
IME12-04NPSZC0S
IME30-15BPSZW7K
IM30-10B-N-ZW0
IME18-08BNSZW2S
