คุณสมบัติ | รายละเอียด |
|---|---|
| Number of Cores | 4 |
| Cross Sectional Area | 0.25 mm² |
| Sheath Colour | Grey |
| Length | 5m |
| Sheath Material | Polyvinyl Chloride PVC |
| Connector 1 Orientation | Straight |
| Connector 1 | M8 |
| Connector 1 Number of Contacts | 4 |
| Connector 1 Gender | Female |
| Connector 2 Housing Gender | Male |
| Connector 2 | M12 |
| Connector 2 Number of Contacts | 4 |
| Connector 2 Orientation | Straight |
| Connector 2 Gender | Male |
| Coding | A |
| Shielded/Unshielded | Unshielded |
| Voltage Rating | 60 V |
| Current Rating | 4 A |
| IP Rating | IP67 |
| Insulation Material | PVC |
| Minimum Operating Temperature | -5°C |
| Cable Shape | Multicore |
| American Wire Gauge | 25 AWG |
| Maximum Operating Temperature | +80°C |
| Connector 1 Housing Gender | Female |
| Outer Diameter | 4.8mm |
| Minimum Bend Radius | 48 mm |
13169 RKMWV 3-224/2 M
15767 RKMWV 4-96/2 M
49311 RSTS 4-RKTS 4-288/3 M
