คุณสมบัติ | รายละเอียด |
---|---|
Coil Voltage | 127 V |
Number of Poles | 3 |
Contact Current Rating | 265 A |
Range | SIRIUS |
Power Rating | 132 kW |
Series | SIRIUS |
Normal State Configuration | 2NO + 2NC |
Number Of Auxiliary Contacts | 2 |
Auxiliary Contact Configuration | 2NO + 2NC |
Terminal Type | Screw |
Length | 210mm |
Width | 145mm |
Depth | 202mm |
Better World Product | Yes |
Better World Claim | Extended product life |
Maximum Operating Temperature | +60°C |
Minimum Operating Temperature | -20°C |
Control Voltage | 110 → 127 V ac/dc |
