คุณสมบัติ | รายละเอียด |
|---|---|
| Series | DPP |
| Type | Switched Mode |
| Electrical Phase | 1 |
| AC or DC Input Voltage | ac, dc |
| Input Voltage | 85 → 264 V ac / 90 → 375V dc |
| AC or DC Output Voltage | dc |
| Output Voltage | 24V dc |
| Output Current | 630mA |
| Power Rating | 15W |
| Number of Outputs | 1 |
| Dimensions | 3.81 x 0.9 x 2.95in |
| Depth | 96.7mm |
| Width | 23mm |
| Height | 75mm |
| Maximum Temperature | +71°C |
| Ripple And Noise | 50mV |
| Minimum Temperature | -10°C |
| Mounting Type | DIN Rail Mount |
| MTBF | 287000h |
| Load Regulation | ±0.5% |
