คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 5V dc |
| Contact Configuration | DPDT |
| Mounting Type | Surface Mount |
| Maximum Switching Current DC | 1 A |
| Maximum Switching Voltage AC | 150V ac |
| Maximum Switching Voltage DC | 125V dc |
| Series | P1 |
| Maximum Switching Power DC | 30 W |
| Latching | No |
| Length | 13.5mm |
| Depth | 7.2mm |
| Height | 8mm |
| Dimensions | 14 x 8 x 7.8mm |
| Terminal Type | Surface Mount |
| Number of Poles | 1 |
| Switching Current | 1A |
| Application | Automotive Equipment, CAN Bus, Imobilizer, Measurement & Control Equipment, Medical Equipment, Office Equipment, Safety Equipment Number of Contacts & Type Contact Assembly |
| Coil Power | 80mW |
| Maximum Switching Power AC | 37.5VA |
| Life | 1000000000 (Mechanical) Operations, 50000000 (Electrical) Operations |
| Coil Resistance | 313Ω |
| Minimum Operating Temperature | -40°C |
| Standards Met | cULus |
| Contact Material | Gold Plated |
| Features | Immersion Cleanable, Directly Trigger able With TTL Standard Modules |
| Operating Temperature Range | -40 - +85°C |
| Maximum Operating Temperature | +85°C |
| Isolation Coil To Contact | 1.5kV rms |
G6K-2F-Y DC5
1-1462038-6
