คุณสมบัติ | รายละเอียด |
|---|---|
| Terminated/Unterminated | Unterminated |
| Coaxial Type | RG400 |
| Outer Diameter | 5.08mm |
| Characteristic Impedance | 50 Ω |
| Attenuation | 100.7 dB/100m @ 3GHz, 31.3 dB/100m @ 400MHz |
| Length | 100m |
| Sheath Colour | Black |
| Conductor Strand Type | Stranded |
| Number of Strands | 19 |
| Maximum Operating Temperature | +105°C |
| Size of Strands | 32 AWG |
| Conductor Material | Silver Plated Copper |
| Operating Temperature Range | -30 - +105 °C |
| Insulation Material | Rayfoam |
| Capacitance | 98pF/m |
| Core Strands | 19/32 |
| Sheath Material | Low Smoke Zero Halogen (LSZH) |
| Minimum Operating Temperature | -30°C |
| Velocity ratio | 71% |
