คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 5V dc |
| Contact Configuration | DPDT |
| Mounting Type | PCB Mount |
| Maximum Switching Current DC | 2 A |
| Maximum Switching Voltage AC | 250V ac |
| Maximum Switching Voltage DC | 220V dc |
| Series | MT2 |
| Maximum Switching Power DC | 60 W |
| Latching | No |
| Length | 20.2mm |
| Depth | 10mm |
| Height | 11mm |
| Dimensions | 20.2 x 10 x 11mm |
| Terminal Type | Surface Mount |
| Number of Poles | 2 |
| Switching Current | 2A |
| Application | Signal |
| Coil Power | 400mW |
| Maximum Operating Temperature | +80°C |
| Minimum Operating Temperature | -20°C |
| Contact Material | Gold Plated |
| Features | Bifurcated Contacts, Meets FCC Part 68 And ITU-T K20 |
| Operating Temperature Range | -20 - +80°C |
| Maximum Switching Power AC | 62.5 VA |
| Coil Resistance | 63 Ω |
