คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 24V dc |
| Contact Configuration | SPST |
| Mounting Type | PCB Mount |
| Switching Current | 16A |
| Number of Poles | 1 |
| Latching | No |
| Terminal Type | Through Hole |
| Length | 29mm |
| Coil Resistance | 1.44 kΩ |
| Depth | 12.7mm |
| Series | RT-iPower |
| Minimum Operating Temperature | -40°C |
| Height | 16mm |
| Maximum Operating Temperature | +85°C |
| Contact Material | Silver Alloy |
| Maximum Switching Power AC | 4 kVA |
| Application | Power |
