คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | 5V dc |
| Input Voltage Range | 18 → 75 V dc |
| Power Rating | 1W |
| Input Voltage Nominal | 48 V dc |
| Output Current | 200mA |
| Mounting Type | Through Hole |
| Isolated | Yes |
| Number of Outputs | 1 |
| Package | DIP |
| Isolation Voltage | 1.6kV dc |
| Depth | 9.9mm |
| Length | 13.2mm |
| Width | 9.1mm |
| Series | TDN 1WI |
| Load Regulation | 0.01 |
| Minimum Temperature | -40°C |
| Efficiency | 78% |
| Standards Met | EN 55022, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, MIL-STD-810F |
| Maximum Temperature | +90°C |
