คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | ±24V dc |
| Input Voltage Range | 9 → 36 V dc |
| Power Rating | 100W |
| Input Voltage Nominal | 24 V dc |
| Output Current | 4.2A |
| Mounting Type | Chassis Mount |
| Isolated | Yes |
| Number of Outputs | 2 |
| Package | 1/2 Brick |
| Isolation Voltage | 2.25kV dc |
| Depth | 12.1mm |
| Length | 57.9mm |
| Series | TEP 100WIR |
| Railway Approved | Yes |
| Load Regulation | 0.001 |
| Medical Approved | No |
| Minimum Temperature | -40°C |
| Maximum Temperature | +75°C |
