คุณสมบัติ | รายละเอียด |
|---|---|
| Thread Size | M12 |
| Sensor Technology | Inductive |
| Body Style | Barrel |
| Detection Range | 4 mm |
| Digital Switching Output Type | NPN |
| Output Function | NO |
| Cable Length | 2m |
| Connection Type | Pre-Cabled |
| Supply Voltage | 10 → 36 V dc |
| Length | 37mm |
| IP Rating | IP65, IP67 |
| Mounting Type | Flush |
| Housing Material | Brass |
| Width | 17mm |
| Maximum DC Voltage | 36V |
| Minimum Operating Temperature | -25°C |
| Shielding | Shielded |
| Maximum Switching Frequency | 2.5kHz |
| Reverse Polarity Protection | Yes |
| Maximum Operating Temperature | +70°C |
| Switching Frequency | 2.5 kHz |
| Standards Met | CSA Certified, E2 Certified, UL Listed |
| Series | General Purpose |
| Switching Current | 10 mA |
| Short Circuit Overload Protection | Yes |
