คุณสมบัติ | รายละเอียด |
|---|---|
| Thread Size | M18 |
| Sensor Technology | Inductive |
| Body Style | Barrel |
| Detection Range | 8 mm |
| Output Function | NO |
| Digital Switching Output Type | PNP |
| Connection Type | Pre-Cabled |
| Cable Length | 5m |
| Supply Voltage | 10 → 36 V dc |
| Length | 40.15mm |
| IP Rating | IP65, IP67 |
| Mounting Type | Flush |
| Width | 24mm |
| Housing Material | Brass |
| Maximum DC Voltage | 36V |
| Minimum Operating Temperature | -25°C |
| Shielding | Shielded |
| Short Circuit Overload Protection | Yes |
| Switching Current | 10 mA |
| Maximum Switching Frequency | 1kHz |
| Reverse Polarity Protection | Yes |
| Switching Frequency | 1 kHz |
| Series | General Purpose |
| Maximum Operating Temperature | +70°C |
