คุณสมบัติ | รายละเอียด |
|---|---|
| Series | OsiSense XM |
| Cross Sectional Area | 0.25 mm² |
| Number of Cores | 4 |
| Sheath Material | PVC |
| Length | 2m |
| Sheath Colour | Black |
| Connector 1 Number of Contacts | 4 |
| Connector 1 Orientation | Right Angle |
| Connector 1 Gender | Female |
| Connector 1 | M12 |
| Connector 2 | Unterminated |
| Current Rating | 3 A |
| Voltage Rating | 250 V ac, 300 V dc |
| IP Rating | IP65, IP67 |
| Outer Diameter | 4.6mm |
| Connector 1 Housing Gender | Female |
| Conductor Resistance | 5000 μΩ |
| Insulation Material | PVC |
| Operating Temperature Range | -25 → +80 °C |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +80°C |
| Cable Shape | Multicore |
NEBB-M8G3-P-5-LE3
XS5F-D421-D80-F
DOL-0803-G05MRN
46833 RSMV 4-RKMV 4-225/1,5 M
7000-44511-7940050
