คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 230V |
| Contact Configuration | DPDT |
| Mounting Type | DIN Rail |
| Number of Poles | 2 |
| Maximum Input Voltage | 230V ac/dc |
| Minimum Input Voltage | 24V ac/dc |
| Terminal Type | Spring Clamp |
| Switching Voltage | 250V ac/dc |
| Depth | 12.8mm |
| Height | 88mm |
| Length | 90mm |
| Series | TRZ |
| Contact Material | Silver Alloy |
| Input Current | (ac) 4 mA, (dc) 4mA |
| Standards Met | CE, CULus, EAC, RoHS Compliant |
| Special Features | Illuminated Ejection Lever, Various Protective Circuits in the Input |
| Operating Temperature Range | -40 → +60°C |
| Turn On Time | <14ms |
| Input Voltage Range | 24 → 230V ac/dc |
| Relay Switching Classification | General Purpose Relay |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +60°C |
| Dimensions | 90 x 12.8 x 88mm |
| Turn Off Time | <22ms |
