คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | ±12V dc |
| Input Voltage Range | 21.6 → 26.4 V dc |
| Power Rating | 2W |
| Input Voltage Nominal | 24 V dc |
| Output Current | ±84mA |
| Mounting Type | Through Hole |
| Isolated | Yes |
| Number of Outputs | 2 |
| Package | DIP |
| Isolation Voltage | 1kV dc |
| Length | 20.32mm |
| Width | 10.16mm |
| Depth | 6.88mm |
| Series | IH |
| Load Regulation | ±10% |
| Efficiency | 82% |
| Minimum Temperature | -40°C |
| Maximum Temperature | +85°C |
