คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | 12V dc |
| Input Voltage Range | 10.8 → 13.2 V dc |
| Power Rating | 0.25W |
| Input Voltage Nominal | 12 V dc |
| Output Current | 20.83mA |
| Mounting Type | Through Hole |
| Isolated | Yes |
| Number of Outputs | 1 |
| Package | SIP |
| Isolation Voltage | 1kV dc |
| Width | 6mm |
| Depth | 10.15mm |
| Length | 11.68mm |
| Series | IK |
| Load Regulation | Maximum of 10% |
| Maximum Temperature | +85°C |
| Efficiency | 62% |
| Minimum Temperature | -40°C |
