คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | ±12V dc |
| Input Voltage Range | 4.5 → 18 V dc |
| Power Rating | 3W |
| Input Voltage Nominal | 12 V dc |
| Output Current | ±125mA |
| Mounting Type | Through Hole |
| Isolated | Yes |
| Number of Outputs | 2 |
| Package | SIP |
| Isolation Voltage | 1.6kV dc |
| Width | 10.1mm |
| Depth | 11.7mm |
| Length | 17mm |
| Series | ITP |
| Load Regulation | ±1% |
| Minimum Temperature | -40°C |
| Maximum Temperature | +75°C |
| Standards Met | EN55032, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, UL/IEC/EN/60950-1, 62368-1 |
| Efficiency | 82% |
