คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | ±24V dc |
| Input Voltage Range | 21.6 → 26.4 V dc |
| Power Rating | 1W |
| Input Voltage Nominal | 24 V dc |
| Output Current | ±42mA |
| Mounting Type | Through Hole |
| Isolated | Yes |
| Number of Outputs | 2 |
| Package | SIP |
| Isolation Voltage | 3kV dc |
| Depth | 9.5mm |
| Width | 6mm |
| Length | 19.5mm |
| Series | IV |
| Load Regulation | ±10% |
| Maximum Temperature | +85°C |
| Efficiency | 78% |
| Minimum Temperature | -40°C |
TEN 8-2423WI
TEN 15-2411WI
