คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | ±15V dc |
| Input Voltage Range | 9 → 36 V dc |
| Power Rating | 10W |
| Input Voltage Nominal | 24 V dc |
| Output Current | ±330mA |
| Mounting Type | Through Hole |
| Isolated | Yes |
| Number of Outputs | 2 |
| Package | DIP 24 |
| Isolation Voltage | 1.6kV dc |
| Width | 20.32mm |
| Length | 31.75mm |
| Depth | 10.16mm |
| Series | JTF |
| Load Regulation | ±1% |
| Minimum Temperature | -40°C |
| Maximum Temperature | +105°C |
| Standards Met | EN 55022, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, MIL-HDBK-217F |
