คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | 12V dc |
| Input Voltage Range | 18 → 75 V dc |
| Power Rating | 100W |
| Input Voltage Nominal | 48 V dc |
| Output Current | 8.3A |
| Mounting Type | PCB Mount |
| Isolated | Yes |
| Number of Outputs | 1 |
| Package | Quarter Brick |
| Isolation Voltage | 1.5kV dc |
| Depth | 12.7mm |
| Width | 36.8mm |
| Length | 57.9mm |
| Series | QSB100 |
| Load Regulation | ±0.2% |
| Maximum Temperature | +100°C |
| Standards Met | EN 55022, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, MIL-HDBK-217F, UL 60950-1 |
| Minimum Temperature | -40°C |
