คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | 15V dc |
| Input Voltage Range | 9 → 36 V dc |
| Power Rating | 150W |
| Input Voltage Nominal | 24 V dc |
| Output Current | 12.5A |
| Mounting Type | PCB Mount |
| Isolated | Yes |
| Number of Outputs | 1 |
| Package | Half Brick |
| Isolation Voltage | 1.5kV dc |
| Depth | 13.2mm |
| Width | 57.9mm |
| Length | 61mm |
| Series | QSB150 |
| Load Regulation | ±0.2% |
| Standards Met | EN 55022, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, MIL-HDBK-217F, UL 60950-1 |
| Maximum Temperature | +100°C |
| Minimum Temperature | -40°C |
