คุณสมบัติ | รายละเอียด |
|---|---|
| Output Voltage | 24V dc |
| Input Voltage Range | 9 → 75 V dc |
| Power Rating | 150W |
| Input Voltage Nominal | 9 → 75 V dc |
| Output Current | 6.25A |
| Mounting Type | PCB Mount |
| Isolated | Yes |
| Number of Outputs | 1 |
| Package | Half Brick |
| Isolation Voltage | 1.5kV dc |
| Width | 57.9mm |
| Depth | 12.7mm |
| Length | 61mm |
| Series | QSB15048W |
| Load Regulation | ±0.2% |
| Maximum Temperature | +100°C |
| Efficiency | 89.5% |
| Minimum Temperature | -40°C |
| Standards Met | EN 55022, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, MIL-HDBK-217F |
